Professional heavy-duty hose set designed for airbrushes and paint pressure tanks. This kit includes both a 1/4" Fluid hose and a 5/16" Air hose, offering superior performance for industrial and professional painting tasks.
The inner diameter is 5/16" with a length of 25ft. Both the outer cover and inner tube are made of high-quality EPDM. The middle layer is braided with high-strength fiber thread. Max Working Pressure: 300 PSI | Max Burst Pressure: 1200 PSI.
Designed specifically for transporting paint. 1/4" inner diameter, 25ft length. Equipped with 1/4" NPS rotary inner tooth with back lock copper connectors. Features a high-quality EPDM cover and a PA nylon insulating innermost layer for specialized fluid transport. Max Working Pressure: 500 PSI.
* Size and lengths can be customized upon request.
A1: Our hoses are constructed using high-quality EPDM synthetic rubber for both the inner tube and outer cover, reinforced with high-tensile braided fiber cores for maximum durability and pressure resistance.
A2: The hoses are designed to operate efficiently within a temperature range of -40°C to 160°C (-40°F to 320°F).
A3: The fluid hose is ideal for transporting urethanes, epoxies, lacquers, alkyds, acrylics, primers, polyesters, MEK, glues, latex, and various water-based fluids.
A4: The air hose (5/16") has a maximum working pressure of 300 PSI, while the black fluid hose (1/4") is rated for up to 500 PSI.
A5: Yes, while our standard assembly set is 25 feet, custom sizes and lengths can be manufactured to meet your specific project requirements.
A6: The assembly features high-quality 3-piece swivel fitting solid brass NPS connections, with back-lock type copper connectors for secure attachments.
