| Part No. | Hose Size ID | Hose OD | Working Pressure | Bend Radius | Burst Pressure | Weight | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| in | mm | in | mm | psi | mpa | in | mm | psi | mpa | kg/m | |
| HQ-R1-03 | 3/16" | 4.8 | 0.5 | 12.7 | 3630 | 25 | 3.5 | 89 | 14520 | 100.1 | 0.19 |
| HQ-R1-04 | 1/4" | 6.4 | 0.63 | 15.9 | 3270 | 22.5 | 4 | 102 | 13080 | 90.2 | 0.21 |
| HQ-R1-05 | 5/16" | 7.9 | 0.69 | 17.5 | 3120 | 21.5 | 4.5 | 114 | 12480 | 86 | 0.24 |
| HQ-R1-06 | 3/8" | 9.5 | 0.78 | 19.8 | 2615 | 18 | 5 | 127 | 10460 | 72.1 | 0.33 |
| HQ-R1-08 | 1/2" | 12.7 | 0.91 | 23 | 2320 | 16 | 7 | 178 | 9280 | 64 | 0.41 |
| HQ-R1-10 | 5/8" | 15.9 | 1.03 | 26.2 | 1890 | 13 | 8 | 203 | 7560 | 52.1 | 0.45 |
| HQ-R1-12 | 3/4" | 19 | 1.19 | 30.2 | 1530 | 10.5 | 9.5 | 241 | 6120 | 42.2 | 0.58 |
| HQ-R1-16 | 1" | 25.4 | 1.5 | 38.1 | 1280 | 8.8 | 12 | 305 | 5120 | 35.3 | 0.611 |
| HQ-R1-20 | 1 1/4" | 31.8 | 1.81 | 46 | 920 | 6.3 | 16.5 | 419 | 3680 | 25.4 | 1.1 |
| HQ-R1-24 | 1 1/2" | 38.1 | 2.06 | 52.4 | 730 | 5 | 20 | 508 | 2920 | 20.1 | 1.51 |
| HQ-R1-32 | 2" | 50.8 | 2.63 | 66.7 | 580 | 4 | 25 | 635 | 2320 | 16 | 1 |
